The TS4466-X4RVPE is a high-performance 4MP PTZ IP camera built for sophisticated outdoor surveillance in sprawling outdoor spaces. Equipped with a 4-megapixel image sensor, 30X optical zoom, fast pan/tilt rotation, and intelligent AI analytics, this ruggedized PoE+ PTZ camera provides superior video quality, long-range surveillance, and smart threat alerts for critical infrastructure, city-wide surveillance, commercial real estate, and transportation infrastructure.

With H.265+ compression, IP66 weather-resistant housing, and infrared night vision up to 150 meters, the TS4466-X4RVPE is designed for continuous monitoring, day and night, even in the most demanding light and weather conditions.

Ultra HD 4MP Resolution with Enhanced Clarity

Central to the TS4466-X4RVPE PTZ outdoor camera is a high-performance 1/2.8" progressive scan CMOS sensor that's able to render 2560 x 1440 resolution video at up to 60fps. This ensures you get extremely clear video for facial recognition, license plate scanning, and real-time situational awareness.

Video Features:

• Actual 4MP (1440p) UHD resolution
• Real-time recording at 30/60fps
• H.264 / H.265 / H.265+ triple codec
• Actual Wide Dynamic Range (WDR) for difficult lighting

Whether deployed in day or challenging lighting environments, this 4MP PTZ dome camera provides unparalleled image definition and color accuracy.

30X Optical Zoom with Accurate PTZ Control

TS4466-X4RVPE PTZ camera comes with a 30X motorized zoom lens, allowing operators to cover vast areas and focus on detailed inspection without image degradation. With 360° endless pan and -5° to 90° tilt, the camera offers smooth area coverage and precise tracking.

• PTZ Performance:
• 30X optical / 16X digital
• 360° pan, auto-flip support
• Patrol, preset, and pattern functions
• Speed control and preset accuracy

Perfect for airports, city crossroads, seaports, and parking garages, the TS4466-X4RVPE leaves no stone unturned.

AI-Powered Intelligent Video Analytics

Advanced AI-based surveillance technology is embedded in the TS4466-X4RVPE, allowing for accurate object detection, behavior analysis, and real-time alerts. The camera is able to distinguish between humans, vehicles, and irrelevant motion like rain or movement of trees.

AI Functions Include:

• Human and vehicle classification
• Intrusion detection and line crossing
• Loitering, object left/removed detection
• Face detection and smart tracking

The camera's AI video analytics minimize false alarms and enhance event accuracy, saving time and bandwidth.

Night Vision up to 150M with Smart IR Technology

IR Features:

• Up to 150m IR range
• IR cut filter with automatic switch
• Adaptive IR to avoid overexposure
• 24/7 surveillance functions

Enjoy seamless security with robust infrared night vision, even at zero-light.

Built for the Outdoors – IP66 and Vandal-Resistant

Engineered to survive harsh outdoor environments, the TS4466-X4RVPE boasts an IP66 weatherproof and IK10 vandal-resistant housing designed to withstand city streets, industrial areas, and public places.

Durability Features:

• Operating temperature: -40°C to 60°C
• Surge and lightning protection
• Integrated heater and fan
• IK10 anti-vandal housing
• Regardless of environment, the TS4466-X4RVPE PTZ camera is engineered to run year-round with reliability.

Easy Installation using PoE+ and Flexible Mounting

The PoE+ PTZ camera offers support for IEEE 802.3at Power over Ethernet, making cabling easier and allowing for fast, clean installations. Optional installation accessories include ceiling, wall, pole, and corner mounts, with deployment in nearly any configuration.

Mounting & Power Options:

• PoE+ (802.3at) and 24VAC dual powe
• Wall, ceiling, and pole brackets
• Surge and lightning protection
• Plug-and-play with NVR systems

Easy setup makes this camera perfect for fast deployment in public and commercial applications.

ONVIF Compliant & Network Compatible

Completely ONVIF-compliant (Profile S, G, T) and RTSP-compatible, the TS4466-X4RVPE 4MP camera is plug-and-play with the majority of NVRs, VMS platforms, and cloud monitoring systems.

Integration Features:

• ONVIF Profiles S, G, T
• RTSP, HTTP, HTTPS protocols
• Remote configuration using a web browser
• Mobile app and PC CMS support
• This camera provides complete interoperability with present security ecosystems and streamlines remote viewing.

Ideal for High-Security Deployments

The TS4466-X4RVPE is designed for mission-critical security, be it deployed in municipal security, industrial surveillance, or enterprise security. Its high-performance lenses, smart capabilities, and robust build provide unparalleled security for:

• City security systems
• Industrial plant protection
• School and university premisesTHE
• Airports and transport hubs
• Big retail and logistics hubs

Why Opt for TS4466-X4RVPE?

If you’re seeking a 4MP PTZ IP camera that combines long-range zoom, intelligent AI analytics, and rugged outdoor performance, the TS4466-X4RVPE is your ideal solution. It’s a complete package for next-gen security monitoring, offering unmatched visibility, flexibility, and system integration.

Specifications

Camera

Name: AI Road Traffic Radar Pro Bullet Plus Camera

Image Sensor 1/1.8″ Progressive Scan CMOS

Min. Illumination Color: 0.005Lux@F1.6

B/W: 0Lux with IR on

WDR 120dB Super WDR

Shutter Time 1/100000s∼1s

Day/Night Mode Day/Night/Auto/Customize/Schedule

IR Wave Length 850nm (Default); 740nm (Optional)

Illumination Distance Up to 180m

S/N >55dB

Lens

Lens 8~32mm, 4X Optical Zoom

Field of View H44°~H13°/D51°~D15°/V25°~V7°

Mount Φ14

Focus Control Auto/Manual

Aperture F1.6~F1.7

Iris Control Auto

Road Traffic Management

Max. Vehicle Speed 120km/h

Recognition Accuracy >95%

Coverage 2 lanes

Country/Region Supported More than 80 countries and regions

ANPR Distance Up to 95m during the day; Up to 45m during the night with illumination

Attributes Identification Plate Color, Vehicle Type, Vehicle Color, Vehicle Brand, No-plate Vehicle Capture, Vehicle Direction Detection, Speed Detection, Traffic Flow Detection

Smart Traffic Function Evidence Camera Linkage, Specific Lane Management

White/Black List Up to 20,000 records inside the camera

LPR Smart Search Support

Radar

Working Frequency 60GHz, 61~62GHz

Capture Rate >99% (Traffic jam >95%)

Lane Coverage 1~4 Lanes (Recognition ≥95% individually）

Tracking Target Up to 32

Speed Detection Range ±5km/h~±120km/h

Speed Detection Accuracy ±0.36km/h

Detection Distance Up to 90m

Distance Detection Accuracy ±0.4m

Angle Measurement Accuracy ±0.5°

Installation Height 2~7m

Interface

Ethernet 1*RJ45 10M/100M Ethernet Port

Audio I/O 1/1

Alarm I/O 1/1

Video

Max. Image Resolution 2688x1520

Primary Stream 60Hz: 60fps@(2688x1520, 2304x1296, 1920x1080, 1280x720)

50Hz: 50fps@(2688x1520, 2304x1296, 1920x1080, 1280x720)

Secondary Stream 60Hz: 60fps@(704x576, 640x480, 640x360, 352x288, 320x240)

50Hz: 50fps@(704x576, 640x480, 640x360, 352x288, 320x240)

Tertiary Stream 60Hz: 30fps@(1280x720, 704x576, 640x480, 640x360, 320x240)

50Hz: 25fps@(1280x720, 704x576, 640x480, 640x360, 320x240)

Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG

Video Bit Rate 16Kbps∼16Mbps (CBR/VBR adjustable)

Privacy Masking Up to 8 Areas (Mask Area and Mosaic Area are optional)

ROI Up to 8 areas

Image Settings Saturation/Brightness/Contrast/Sharpness

Network

Network Storage NAS(Support NFS, SMB/CIFS), ANR

Network Protocols IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2

Audio

Audio Compression G.711/AAC/G.722/G.726

Audio Sampling Rate 8/16/32/44.1/48KHz

Audio Bit Rate 16~256kbps

Two-way Audio Support

System

System Compatibility API, HTTP, TCP, ONVIF Profile G & M & S & T

Storage Support microSD/SDHC/SDXC Card Local Storage, up to 1TB

Advanced Function BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark

SIP/VoIP Support Yes, Voice&Video-over-IP

Event Trigger Black/White List, Attributes Event, Motion Detection, Network Disconnection, External Input, Audio Alarm, etc.

Event Action FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc

General

Working Temperature -40℃∼60℃

Working Humidity 5~90%(Non-condensing)

Power Supply PoE (802.3at) / DC 12V±10%

Power Consumption 9W MAX

16W MAX (With IR on)

Housing Up to IP67-rated for weather-resistant performance

Surge Protection 4KV

Weight 1623g

Dimensions 320mmX134mmX171mm

Warranty 3/5 Years
