TS4466-X4RWE Overview – 4MP Outdoor PTZ Camera with 30X Optical Zoom, AI Video Analytics, and Weatherproof Design

The TS4466-X4RWE is a cutting-edge 4MP outdoor PTZ camera for long-distance, high-accuracy surveillance in harsh environments. With 30X optical zoom, video analytics with AI, Smart IR night vision support up to 150m, and an IP66-rated weatherproof construction, this camera is the ideal choice for smart security systems, city surveillance, infrastructure guarding, and enterprise deployments.

Whether you require trustworthy day/night monitoring, smart object detection, or true integration with VMS/NVR platforms, the TS4466-X4RWE provides a future-proof surveillance experience with unparalleled image fidelity and system smarts.

4MP Ultra HD Imaging – Unparalleled Detail and Clarity

The TS4466-X4RWE PTZ IP camera provides clear 4MP resolution (2560 × 1440) video through a high-performance 1/2.8" CMOS sensor. The camera records fine details such as facial features, license plates, and object movements, making it perfect for situations where clarity is crucial.

Key Specs:

• 2560 x 1440 resolution at up to 30fps
• True Wide Dynamic Range (WDR) – 120dB
• 3D DNR and BLC for enhanced image processing
• H.265/H.264 compression for bandwidth saving

30X Optical Zoom – Accurate Monitoring from a Distance

With its 30X optical zoom lens, the TS4466-X4RWE can easily recognize people, vehicles, and activities at great distances. Combined with pan (360° endless) and tilt (90°) functionality, this PTZ (Pan-Tilt-Zoom) camera provides wide-area coverage and focused attention when necessary.

Zoom & PTZ Features:

• 30X optical zoom / 16X digital zoom
• 360° endless pan & 90° tilt
• Up to 300 presets, 8 patrols, and auto-tracking
• Variable-speed PTZ control

Ideal for parking lots, borders, ports, and city traffic intersections, this camera picks up details even from a distance.

AI-Powered Video Analytics – Smarter Surveillance

The TS4466-X4RWE AI-driven PTZ camera is fitted with state-of-the-art intelligent video analytics, enabling it to monitor environments around the clock with accuracy and efficiency. Using high-end AI algorithms, this intelligent surveillance camera is able to accurately identify and classify objects like humans, vehicles, and aberrant motion, so alerts are reserved for significant activity only. This greatly minimizes the occurrence of false alarms based on irrelevant motion, like animals, shadows, or changes in the environment—enabling security personnel to focus on real threats and critical events.

 AI Functions:

• Face detection & capture
• Line crossing detection
• Intrusion detection
• Region entrance/exit
• Smart detection of moving objects

With smart behavior analysis, this camera is suitable for smart cities, shopping malls, universities, and factories.

150M Smart IR Night Vision – Clarity in Total Darkness

With high-power IR LEDs and Smart IR technology, the TS4466-X4RWE provides crystal-clear nighttime vision as far away as 150 meters. Whatever you're watching over—your warehouse, dock, or outdoor boundary—this camera has eyes day and night.

Night Vision Highlights:

• IR range: Up to 150 meters
• Smart IR adjusts brightness to avoid overexposure
• True Day/Night switching with IR cut filter
• Crisp black-and-white imaging in low-light
• Conduct 24/7 surveillance without sacrificing image quality.

Rugged IP66 Weatherproof & Vandal-Resistant Design

Build Quality Highlights:

• IP66 weatherproof rating
• IK10 vandal-resistant casing
• Operating temperature: -40°C to +60°C
• Surge and lightning protection

This renders the camera a trustworthy solution for coastal areas, deserts, high-security areas, and transportation centers.

PoE+ and Versatile Installation

Installation Benefits:

• IEEE 802.3at PoE+ support
• Dual power input (PoE+/24VAC)
• Compatible with wall, ceiling, and pole mounts
• Web interface, VMS/NVR support, and mobile apps

Easy to integrate with other systems or develop a new system from scratch at a low infrastructure cost.

ONVIF & VMS Compatibility

Integration Highlights:

• ONVIF Profiles S / G / T
• Remote access using the mobile app or a web browser
• HTTPS/FTP/NTP/DDNS support
• Compliant with third-party platforms such as Milestone, Genetec, etc.
• Facilitate seamless integration into any professional video management system.
• Applications – Where to Install the TS4466-X4RWE

The TS4466-X4RWE PTZ camera is designed especially for challenging, high-security installations that need vast area coverage, accurate tracking, and reliable operation in all kinds of weather.

Designed to provide long-range visibility with its powerful 30X optical zoom and intelligent AI tracking feature, this advanced outdoor IP camera guarantees key areas are under constant watch. Whether utilized in urban surveillance areas, border patrol locations, transportation terminals, government buildings, or industrial estates, the TS4466-X4RWE performs optimally in providing uninterrupted 360-degree situational awareness. Suggested Applications:

• City surveillance & public safety
• Border and perimeter security
• Large retail centers & commercial properties
• Universities, campuses & stadiums
• Transportation hubs (airports, stations, ports)
• Industrial sites, oil & gas, construction

Where smart, scalable, and high-resolution security is required, this camera delivers without exception.

Why opt for the TS4466-X4RWE PTZ Camera?

If you need a powerful, AI-enabled, and extended PTZ security solution, the TS4466-X4RWE meets all your needs. From 4MP resolution and 30X zoom to smart analytics, IP66 weatherproofing, and 150M night vision, the camera is designed for high-stakes outdoor surveillance missions.

Specifications

Camera

Name AI Road Traffic Supplement Light Pro Bullet Plus Camera

Image Sensor 1/1.8″ Progressive Scan CMOS

Min. Illumination Color: 0.002Lux@F1.6

B/W: 0Lux with IR on

WDR 140dB Super WDR

Shutter Time 1/100000s~1s

Day/Night Mode Day/Night/Auto/Customize/Schedule

S/N >55dB

Lens

Lens 8~32mm, 4X Optical Zoom

Field of View H44°~H13°/D51°~D15°/V25°~V7°

Mount Φ14

Focus Control Auto/Manual

Aperture F1.6-F1.7

Iris Control Auto

Road Traffic Management

Max. Vehicle Speed 120km/h

Recognition Accuracy >95%

Coverage 2 lanes

Country Region Supported More than 80 countries and regions

ANPR Distance Up to 95m during the day; Up to 50m during the night with illumination

Attributes Identification Plate Color, Vehicle Type, Vehicle Color, Vehicle Brand,

No-plate Vehicle Capture, Vehicle Direction Detection

Smart Traffic Function Evidence Camera Linkage, Specific Lane Management

White/Black List Up to 20,000 records inside the camera

LPR Smart Search Support

Illuminator

Supplement Light White LED Light / IR LED Light

Light Bead 6 (For White LED Light) / 9 (For IR LED Light)

Illumination Distance Up to 180m

IR Wave Length

(For IR LED Light) 850nm (Default); 740nm (Optional)

Light Control Auto/Always On/Off/Customize

Interface

Ethernet 1*RJ45 10M/100M Ethernet Port

Audio I/O 1/1

Alarm I/O 2/2

Wiegand Standard Wiegand 26-bit

Video

Max. Image Resolution 2688x1520

Primary Stream 60Hz: 60fps@(2688x1520, 2304x1296, 1920x1080, 1280x720)

50Hz: 50fps@(2688x1520, 2304x1296, 1920x1080, 1280x720)

Secondary Stream 60Hz: 60fps@(704x576, 640x480, 640x360, 352x288, 320x240)

50Hz: 50fps@(704x576, 640x480, 640x360, 352x288, 320x240)

Tertiary Stream 60Hz: 30fps@(1280x720, 704x576, 640x480, 640x360, 320x240)

50Hz: 25fps@(1280x720, 704x576, 640x480, 640x360, 320x240)

Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG

Video Bit Rate 16Kbps~16Mbps(CBR/VBR Adjustable)

Privacy Masking Up to 8 Areas (Mask Area and Mosaic Area are optional)

ROI Up to 8 areas

Image Setting Brightness/Contrast/Saturation/Sharpness

Network

Network Storage NAS(Support NFS, SMB/CIFS), ANR

Protocol IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP,UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2

Audio

Audio Compression G.711/AAC/G.722/G.726

Audio Sampling Rate 8/16/32/44.1/48KHz

Audio Bit Rate 16~256kbps

Two-way Audio Support

System

System Compatibility API, HTTP, TCP, Wiegand Protocol, ONVIF Profile G & M & S & T

Storage Support microSD/SDHC/SDXC Card Local Storage, up to 1TB

Advanced Function BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC,

Anti-flicker, Corridor Mode, Deblur, Watermark

SIP/VoIP Support Yes, Voice & Video-over-IP

Event Trigger Black/White List, Attributes Event, Motion Detection,

Network Disconnection, External Input, Audio Alarm, etc.

Event Action FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc.

General

Working Temperature -40℃~60℃

Working Humidity 5~90%(Non-condensing)

Power Supply DC 12V / 3A±10% (Non-PoE)

Power Consumption 4W MAX,28W MAX (For White LED Light)

4W MAX,28W MAX (For IR LED Light)

Surge Protection 4KV

Weather Proof Up to IP67-rated for Weather-resistant Performance

Housing Vandal-proof IK10-rated Metal Housing (Without Supplement Light)

Surge Protection 4KV

Weight 1445.8g

2100g (With Supplement Light)

Dimensions 282mmX108mmX120mm

282mmX108mmX225mm (With Supplement Light)

Warranty 3/5 Years
