When accuracy, toughness, and smart monitoring are essential, the MS-C2964-R(T)F(I)PE is an industry-leading solution for businesses and organizations. With its high-performance 4MP security camera, it provides high-definition video, smart analytics, and durable outdoor performance, and is among the top surveillance cameras for industrial, commercial, and public safety uses.
In this in-depth review, we'll cover everything you should know about the MS-C2964-R(T)F(I)PE and why it's essential for any serious security system.
The MS-C2964-R(T)F(I)PE features market-leading features designed for maximum surveillance performance:
4MP High-Resolution Video: Record clear, detailed images at 2560 × 1440 resolution — ideal for watching faces, license plates, and key areas.
Smart Infrared Night Vision: With its strong night vision IP camera, it provides clear monitoring in total darkness up to 30 meters.
True Wide Dynamic Range (WDR): 120dB WDR technology compensates for light and dark scenes, ensuring clear images in high-contrast environments.
IP67 Weatherproof Rating: This tough outdoor IP camera withstands dust, rain, and extreme weather, making it suitable for long-term outdoor deployment.
Smart Video Analytics: Motion detection, intrusion detection, and line-crossing alert features offer advanced security.
H.265 Video Compression: H.265 video compression technology stores less space while maintaining video quality by using efficient compression.
PoE Support: Make installation easy and minimize wiring hassles with Power over Ethernet (PoE) support.
Flexible Lens Options: Select between 2.8mm, 4mm, or 6mm lens options for monitoring large areas or focusing on specific areas.
Offering 4MP image definition, MS-C2964-R(T)F(I)PE guarantees pivotal details are not left behind. For watching entries, parking garages, and assembly lines, the high-definition video surveillance camera offers everything in picture-perfect precision.
Built to withstand harsh environments, this rainproof CCTV camera can endure pouring rain, blizzards, and dust storm conditions. Being IP67 compliant, you know that the MS-C2964-R(T)F(I)PE will get the job done every season.
The inherent smart analytics aid you in the proactive detection of unusual activities. Intrusion detection, region entry/exit surveillance, and line-crossing alarms render it a real smart security solution for rapid response and inquiry.
With high-efficiency H.265 video compression, the MS-C2964-R(T)F(I)PE minimizes bandwidth and storage needs without sacrificing video integrity. This is imperative for organizations ramping up video surveillance solutions without increasing operational costs.
Being a PoE security camera, it also makes installation easier by providing power as well as data transmission via a single Ethernet cable. For retrofitting an existing security system or for new deployments, the camera reduces installation cost and complexity.
The MS-C2964-R(T)F(I)PE performs exceptionally well in a diverse range of environments. This device has been designed to meet the demands of various settings, making it a versatile choice for users who need a reliable and efficient solution. Its adaptability allows it to function effectively in different scenarios, whether it be in a small office, a large enterprise, or even in more challenging environments such as industrial sites or outdoor locations. Retail Security: Protect stores, shopping centers, and storefronts against theft and enhance customer safety.
Transportation Terminals: Install in airports, bus terminals, and metro stations to secure passengers and employees.
Industrial Plants: Fortify factories, warehouses, and plants with an industrial security camera designed for harsh environments.
Public Parks: Safeguard parks, city squares, and stadiums with a weather-resistant CCTV camera that runs 24/7.
Residential Communities: Install at gates, lobbies, and parking garages for complete community monitoring.
To achieve optimum performance with your MS-C2964-R(T)F(I)PE:
Select Strategic Positions: Install cameras at entrances, exits, and vulnerable points to cover more ground.
Adjust the Lens Properly: Use the correct lens (2.8mm for wide fields, 4mm/6mm for faraway distances) depending on the area.
Set up Smart Alerts: Optimize detection zones and sensitivity levels to reduce false alarms.
Clean Lens: Clean the lens regularly to achieve optimum image quality, particularly for outdoor installations.
Integrate with a VMS: Link the camera to a professional Video Management System to enable centralized monitoring and recording.
The MS-C2964-R(T)F(I)PE provides an unmatched mix of excellent imaging, smart features, weather-resistant ruggedness, and simple installation. Securing a busy retail plaza, an industrial complex, or a residential complex, this 4MP security camera gives you the confidence you require.
With smart video analytics, night vision capabilities, and efficient H.265 compression, it ranks among the best surveillance cameras for today’s dynamic security needs.
If you're looking for a high-definition, weatherproof, and smart outdoor IP camera, the MS-C2964-R(T)F(I)PE is a perfect choice — reliable, efficient, and built for the future of professional video surveillance.
| Camera | |
|---|---|
| Name | AI Motorized Bullet Network Camera |
| Image Sensor | 1/2.8″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.005Lux@F1.4 B/W: 0Lux with IR on |
| WDR | 140dB Super WDR |
| Shutter Time | 1/100000s~1s |
| DORI Distance | D: 44~194m O: 17~80m R: 8~39.5m l: 3~19.5m |
| IR Distance | Up to 50m |
| Day/Night Mode | Day/Night/Auto/Customize/Schedule |
| S/N | >55dB |
| Lens | |
| Lens | Motorized 2.7~13.5mm/3.0~10.5mm/7~22mm@F1.4 P-Iris(Optional) |
| Mount | Φ14 |
| Field of View | H111°~H34°/D130°~D39°/V60°~V19°(2.7~13.5mm) H100°~H33°/D115°~D38°/V54°~V18°(3.0~10.5mm) H42°~H17°/D48°~D19°/V24°~V9° (7~22mm) |
| Focus Control | Auto/Manual |
| Iris Control (Optional for I Series) | Auto/Manual |
| Video | |
| Max. Image Resolution | 1920x1080 |
| Primary Stream | 60Hz: 90fps@(1920x1080)(Optional for T Series), 60fps@(1920x1080, 1280x960, 1280x720, 704x576) 50Hz: 90fps@(1920x1080)(Optional for T Series), 50fps@(1920x1080, 1280x960, 1280x720, 704x576) |
| Secondary Stream | 60Hz: 60fps@(704x576, 640x480, 640x360, 352x288, 320x240) 50Hz: 50fps@(704x576, 640x480, 640x360, 352x288, 320x240) |
| Tertiary Stream | 60Hz: 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 352x288, 320x240) 50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 352x288, 320x240) |
| Video Compression | H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Video Bit Rate | 16Kbps~16Mbps(CBR/VBR Adjustable) |
| Image | |
| Privacy Masking | Up to 8 Areas (Mask Area and Mosaic Area are optional) |
| ROI | Up to 8 areas |
| Image Setting | Brightness/Contrast/Saturation/Sharpness |
| Image Enhancement | BLC, HLC, 2D DNR, 3D DNR, AGC, Defog, AWB, Deblur, Anti-flicker, Corridor Mode, LDC (Unsupported for 3-10.5mm Lens) |
| Interface | |
| Ethernet | 1*RJ45 10M/100M Ethernet Port |
| Audio I/O | 1/1 (Multi-interface Version) |
| Alarm I/O | 1/1 (Multi-interface Version) |
| Network | |
| Network Storage | NAS(Support NFS, SMB/CIFS), ANR |
| Protocol | IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2 |
| Audio | |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Audio Sampling Rate | 8/16/32/44.1/48KHz |
| Audio Bit Rate | 16~256kbps |
| Intelligent Analytics | |
| Video Analysis | VCA 2.0: Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection, Line Crossing, Loitering, Object Left, Object Removed |
| Face Detection & Face Attribute Recognition | Detect and capture faces, get real-time snapshots. The attributes include Age, Gender, Glasses, Mask, and Cap. Support Faces Privacy Mode, the detected faces in the face detection area will be mosaicked automatically |
| Object Counting & Report | Count the number of objects crossing the line, optionally human and vehicle. Support regional people counting for up to 4 detection areas |
| Heat Map | The built-in statistical behavior analysis enables you to identify the busiest areas within the environment |
| Event | |
| Basic Event | Motion Detection,Tamper Detection, Network Disconnection, etc. |
| Exception | Network Disconnection, IP Address Filtering, Record Failed, SD Card Full, SD Card Uninitialized, SD Card Error, No SD Card, Watermark |
| Event Action | FTP Upload, SMTP Upload, SD Card Record, SIP Phone, HTTP Notification, etc. |
| System | |
| Storage | Support microSD/SDHC/SDXC Card Local Storage, up to 1TB |
| SIP/VoIP Support | Yes, Voice & Video-over-IP |
| System Compatibility | ONVIF Profile G & M & S & T, API |
| General | |
| Working Temperature | -40℃~60℃ |
| Working Humidity | 0~95%(Non-condensing) |
| Power Supply | PoE (802.3af) / DC 12V±10% |
| Power Consumption | Min.: 2.5W (DC 12V), 3.5W(PoE) Max.: 9.5W (DC 12V), 11.5W(PoE) |
| Weight | 825g |
| Dimensions | Φ76mmX239.5mm |
| Warranty | 3/5 Years |
| Certifications | |
| EMC | CE-EMC (EN 55032, EN 55035), FCC (PART 15B) |
| Safety | CE-LVD (EN IEC 62368-1) |
| Environment | CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU) |
| Protection | IP67, IK10 |
