With security threats changing at a breakneck pace, it is no longer a choice but a necessity to have an intelligent, responsive, and high-definition surveillance system. The MS-C2967-X12R(T)PE PTZ camera is a professional-level solution that is capable of fulfilling the high standards of industrial security, critical infrastructure monitoring, citywide surveillance, and commercial facility protection.

With 4MP resolution, 12X optical zoom, AI video analytics, and Smart IR night vision combined, this network PTZ camera provides industry-leading performance in an ultra-compact and weather-resistant package. Installed for wide area coverage or detailed monitoring, this model delivers excellent performance in any lighting and weather conditions.

Most Important Features of the MS-C2967-X12R(T)PE PTZ Security Camera

12X Optical Zoom Lens for Long-Range Clarity

With a motorized 12X zoom lens (5.3mm – 64mm), this high-resolution PTZ camera is capable of capturing high details at far distances. Ideal for vehicle license plate reading, facial recognition, and surveillance over large areas such as airports, factories, and parking garages. The autofocus and zoom harmonize to provide silky-smooth transitions and razor-sharp images.

Crystal-Clear 4MP Resolution

This Ultra HD 4MP security camera provides outstanding picture quality at 2560 x 1440 resolution, providing clear and vivid vision for real-time monitoring and playback. With its progressive scan CMOS sensor, the camera reduces motion blur and distortion for superior forensic-quality video evidence.

Smart IR LEDs with 100m Night Vision

With adaptive Smart IR infrared lighting, the MS-C2967-X12R(T)PE attains trustworthy night-time vision as far as 100 meters. In contrast to conventional IR, Smart IR does not cause close objects to become overexposed, thus best suited for outdoor surveillance, perimeter security, and low-light situations.

360° Endless Pan & 90° Tilt Rotation

The mechanical structure of the camera provides all 360-degree pan and 5° to 90° tilt capabilities, providing comprehensive area coverage. This makes it a perfect fit for public safety systems, city traffic observation, and logistics location management. Preset points and auto-patrol settings add to automated security programs.

Built-in AI Video Analytics

This PTZ camera with AI has intelligent capabilities like human detection, vehicle detection, region entrance/exit, line crossing, and object removal detection. All these smart detection algorithms assist security teams in eliminating false alarms and reacting to genuine threats in real time.

Outdoor Ready: IP66 & IK10 Rated

Its IP66-proof and IK10 vandal-proof body makes it perfectly suited to adverse weather and hazardous environments. It's installed whether it goes up in a bustling city center or an industrial factory, providing consistent reliability.

PoE+ (Power over Ethernet Plus) Ready

Streamline installs with support for PoE+ (IEEE 802.3at)—send power and carry data via one cable. Installing the camera in out-of-sight, off-the-beaten-path places becomes simpler and cheaper.

H.265+ Storage-Efficient Compression

Decrease storage requirements and bandwidth utilization with H.265+ video compression technology. This effective codec makes it possible for network video recorders (NVRs) and cloud video platforms to support more streams with less storage, perfect for enterprise surveillance solutions.

Top MS-C2967-X12R(T)PE Use Cases

● Smart City Surveillance

Protect intersections, urban plazas, transportation terminals, and public parks with AI object detection and extended-range PTZ coverage.

● Critical Infrastructure Security

Install this industrial-strength IP camera to safeguard data centers, power plants, water treatment plants, and telecommunication stations.

● Commercial Property & Campus Monitoring

Perfect for large commercial properties, retail malls, schools, and sports facilities, the camera provides smart patrol paths and event-driven recording.

● Logistics & Warehousing

Secure gates, vehicle bays, and warehouse perimeters with extended-range infrared coverage and vehicle recognition analytics.

● Airport & Seaport Surveillance

Have all runways, terminals, docks, and security checkpoints in high view with AI-powered event detection and high-zoom PTZ tracking.

A Quick Look at the Key Benefits

Long-Range Optical Zoom: See remote objects clearly.

AI-Powered Security: Suppress false alarms and improve incident detection rates.

Universal PTZ Control: Dynamic PTZ viewing angles cover extensive areas with ease.

All-Weather Toughness: Engineered for durable, harsh outdoor usage.

Easy Installation: Simple PoE+ wiring and distant setup.

Storage Optimization: H.265+ compression reduces cloud and local storage costs.

Is the MS-C2967-X12R(T)PE the Right Choice for You?

If you're looking for a flexible, AI-powered, and rugged PTZ camera that provides accurate surveillance over wide spaces and in challenging environments, the MS-C2967-X12R(T)PE is your best bet. Its smart video capabilities, optical zoom, night vision, and integration flexibility make it an invaluable tool for anyone designing a scalable and secure IP camera system.

Whichever your role as integrator, facility manager, or government agency, this camera increases visibility, eliminates blind spots, and enhances your entire video surveillance infrastructure

Specifications

Camera

Model MS-C2967-X12R(T)PE

Image Sensor 1/2.8″ Progressive Scan CMOS

Min. Illumination Color: 0.005Lux@F1.6

B/W: 0Lux with IR on

WDR 140dB Super WDR

(Super WDR Pro is optional for T Series)

Shutter Time 1/100000s~1s

DORI Distance D: 82.5~996m  O: 32.5~392m

R: 16~196m  l: 8~98m

IR Distance Up to 180m

Digital Zoom 16X

Day/Night Mode, Day/Night/Auto/Customize/Schedule

S/N >55dB

Lens

Focal Length 5.3~64mm, 12X Optical Zoom

Zoom Speed Approx 4s (Wide-Tele)

Field of View H61°~H5°/D69°~D5°/V36°~V2°

Focus Control Auto/Semi-Auto/Manual

Minimum Working Distance 1000/1500mm (Wide/Tele)

Aperture F1.6~F2.8

Iris Control Auto

PTZ

Pan Range/Pan Speed 360°endless / Pan Manual Speed: 0.1°~50°/s, Pan Preset Speed: 50°/s

Tilt Range/Tilt Speed -45°~30° / Tilt Manual Speed: 0.1°~30°/s, Tilt Preset Speed: 30°/s

Proportional Zoom Support

Preset Quantity 300

Patrol 8 Patrols, up to 48 presets each patrol

Pattern 4 Patterns

Auto Tracking Support

Power Off Memory Support

Other Function: Auto Scan, Auto Home, Preset Freezing, 3D Positioning, PTZ Limits, Initial Position

Video

Max. Image Resolution 1920x1080

Primary Stream 60Hz: 90fps@(1920x1080)(Optional for T Series),60fps@(1920x1080, 1280x960, 1280x720, 704x576)

50Hz: 90fps@(1920x1080)(Optional for T Series),50fps@(1920x1080, 1280x960, 1280x720, 704x576)

Secondary Stream 60Hz: 60fps@(704x576, 640x480, 640x360, 352x288, 320x240)

50Hz: 50fps@(704x576, 640x480, 640x360, 352x288, 320x240)

Tertiary Stream 60Hz: 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)

50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)

Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG

Video Bit Rate 16Kbps~16Mbps(CBR/VBR Adjustable)


Privacy Masking Up to 8 Areas (Mask Area and Mosaic Area are optional)

ROI Up to 8 areas

Image Setting Brightness/Contrast/Saturation/Sharpness

Image Enhancement BLC, HLC, 2D DNR, 3D DNR, AGC, Defog, AWB, Deblur, Anti-flicker, Corridor Mode, LDC

Interface

Ethernet 1*RJ45 10M/100M Ethernet Port

Audio I/O 1/1

Alarm I/O 1/1

Network

Network Storage NAS(Support NFS, SMB/CIFS), ANR

Protocol IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2

Audio

Audio Compression G.711/AAC/G.722/G.726

Audio Sampling Rate 8/16/32/44.1/48KHz

Audio Bit Rate 16~256kbps

Intelligent Analytics

Video Analysis VCA 2.0: Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection,

Line Crossing, Loitering, Object Left, Object Removed

Attribute Extraction Simultaneously detects up to 50 targets and capture humans and vehicles in real time.

Recognize attributes including Upper and Lower Clothing Color, Hat, and Vehicle Types (Bicycle, Car, Motorcycle, Bus, Truck, E-scooter).

Face Detection & Face Attribute Recognition Detect and capture faces, get real-time snapshots.  The attributes include Age, Gender, Glasses, Mask, and Cap.

Support Faces Privacy Mode, the detected faces in the face detection area will be mosaic automatically.

Object Counting & Report Count the number of objects crossing the line, including humans and vehicles.

Support regional people counting for up to 4 detection areas

Event

Basic Event Motion Detection, Tamper Detection, Network Disconnection, External Input, Audio Alarm, etc.

Exception Network Disconnection, IP Address Filtering, Record Failed, SD Card Full, SD Card Uninitialized, SD Card Error, No SD Card, Watermark

Event Action: FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, White LED, PTZ Motion, HTTP Notification, etc.

System

Storage Support microSD/SDHC/SDXC Card Local Storage, up to 1TB

SIP/VoIP Support Yes, Voice & Video-over-IP

System Compatibility ONVIF Profile G & M & S & T, API

General

Working Temperature -40℃~60℃

Working Humidity 0~90%(Non-condensing)

Power Supply PoE (802.3at) / DC 12V/3A±10%

Power Consumption Min.: 10.8W (DC 12V), 12.7W(PoE)

Max.: 21.4W (DC 12V), 25.3W(PoE)

Weight 2.9Kg

Dimensions 110mmX337mmX220mm

Warranty 2 Years / 3 Years (Optional)

Certifications

EMC CE-EMC (EN 55032, EN 55035), FCC (PART 15B)

Safety CE-LVD (EN IEC 62368-1)

Environment CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU)

Protection IP66
