5G AI Motorized Pro Bullet Plus Network Camera

The MS-C2966-RF(I)GPE is a high-grade 2MP PTZ (Pan-Tilt-Zoom) AI network camera, designed for high-performance surveillance in challenging environments. With advanced AI video analytics, accurate optical zoom, robust night vision, and weather-resistant ruggedness, this high-end PTZ surveillance camera is suitable for a broad variety of security applications, from city surveillance and critical infrastructure protection to transportation terminals, industrial areas, and public safety monitoring.

This summary points out the camera's solid feature set and shows why the MS-C2966-RF(I)GPE is an ideal solution for enterprises and government agencies looking for intelligent, all-weather, high-precision monitoring.

Full HD 2MP Resolution for Crystal-Clear Monitoring

The MS-C2966-RF(I)GPE has a 2MP CMOS image sensor that captures 1920 x 1080 Full HD resolution. This provides crystal-clear imaging for both live and stored footage, making it easy for security personnel to read faces, license plates, objects, and incidents. Either used in daytime or nighttime settings, the camera ensures consistently excellent imaging for productive monitoring.

Precision PTZ Control for Complete Coverage

This PTZ camera offers 360° constant panning, 2° to 90° pan tilt, and 12x optical zoom to cover vast areas without blind spots. The digital 16x zoom also provides enhanced visibility for real-time focus on remote objects or target areas.

Designed for extensive outdoor surveillance applications, including ports, warehouses, and highways, the MS-C2966-RF(I)GPE provides expanded coverage and zoom-in functionality without compromising image quality.

AI-Powered Intelligent Video Analytics

The camera has built-in AI video analytics, which makes surveillance smarter and more proactive. The system can:

• Detect humans and vehicles
• Recognize faces
• Detect line crossing and intrusions
• Auto-track moving subjects
• Count people and analyze crowds

This AI capability eliminates false alarms, enhances monitoring accuracy, and automates responses in smart city applications, airports, train stations, and critical infrastructure sites.

Smart IR Night Vision up to 150 Meters

Fitted with powerful infrared (IR) LEDs, the MS-C2966-RF(I)GPE provides Smart IR night vision of up to 150 meters. This allows the camera to provide clear images even in complete darkness. The IR intensity is automatically adjusted according to the object distance to prevent overexposure and improve night-time clarity.

It's perfect for perimeter security, parking garages, airports, and building sites that need constant surveillance.

Built for Harsh Outdoor Environments

The MS-C2966-RF(I)GPE features an IP66-rated weatherproof enclosure and IK10 vandal-resistant housing. It is dustproof, rainproof, snowproof, windproof, and impact-resistant, making it a durable option for outdoor installations in high-risk public spaces, industrial estates, and remote infrastructure sites.

The rugged construction of the camera guarantees seamless operation irrespective of extreme weather conditions, thus ensuring maximum uptime and reduced maintenance.

Advanced Auto-Tracking for Target Monitoring

With smart auto-tracking, the camera can automatically spot and track a moving subject, like a person or vehicle, within its field of view. When motion is detected, the camera pans, tilts, and zooms to maintain the target in the center, minimizing the need for human intervention.

This is especially helpful in border patrol, high-security areas, and transportation terminals, where real-time threat response is paramount.

PoE+ for Simple Installation and Integration

MS-C2966-RF(I)GPE has Power over Ethernet Plus (PoE+) capability, making it easy to install since power as well as data can be transferred via a single cable. It minimizes the complexity of wires and installation, particularly in out-of-the-way or remote places.

The camera is also ONVIF-compatible, guaranteeing compatibility with most NVRs, VMS platforms, and third-party security systems.

Widely applicable across industries

Due to its versatile deployment, smart features, and tough durability, the MS-C2966-RF(I)GPE is ideal for various industry applications:

Urban security and smart city initiatives

Government and military bases

Utility and energy sites

Transportation infrastructure (airports, railways, highways)

Logistics centers and distribution facilities

Border control and perimeter protection

Its versatility guarantees scalable protection across diverse sectors, providing enterprise-grade surveillance and real-time incident management.

The MS-C2966-RF(I)GPE PTZ Network Camera is an advanced and forward-thinking security solution for any organisation concerned with security, intelligence, and flexibility. It combines AI-based functionality with top-notch imaging, interference-free control, and a hardened physical design to deliver full coverage in any setting.

Whether you are securing city streets, guarding valuable assets, or improving real-time situational awareness, this AI PTZ IP camera is designed to provide reliable performance and actionable intelligence. Investing in the MS-C2966-RF(I)GPE is investing in next-generation surveillance technology.

Specifications

Camera

Name 2MP 5G AI Motorized Pro Bullet Plus Network Camera

Image Sensor 1/2.8″ Progressive Scan CMOS

Min. Illumination Color: 0.005Lux@F1.4

B/W: 0Lux with IR on

WDR 140dB Super WDR

Shutter Time 1/100000s~1s

Day/Night Mode Day/Night/Auto/Customize/Schedule

IR Distance Up to 65m(2.7~13.5mm)

Up to 100m(7~22mm)

S/N >55dB

Lens

Lens Motorized 2.7~13.5mm/7~22mm@F1.4, P-Iris(Optional)

Field of View H113°~H33°/D130°~D38°/V60°~V18° (2.7~13.5mm)

H45°~H17°/D53°~D20°/V25°~V9° (7~22mm)

Mount Φ14

Focus Control Auto/Manual

Iris Control Auto/Manual (Optional for I Series)

Video

Max. Image Resolution 1920x1080

Primary Stream 60Hz: 60fps@(1920x1080, 1280x960, 1280x720, 704x576)

50Hz: 50fps@(1920x1080, 1280x960, 1280x720, 704x576)

Secondary Stream 60Hz: 60fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180)

50Hz: 50fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180)

Tertiary Stream 60Hz: 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x180)

50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x180)

Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG

Video Bit Rate 16Kbps~16Mbps(CBR/VBR Adjustable)

Privacy Masking Up to 8 Areas (Mask Area and Mosaic Area are optional)

ROI Up to 8 areas

Image Settings Brightness/Contrast/Saturation/Sharpness

Audio

Audio Compression G.711/AAC/G.722/G.726

Audio Sampling Rate 8/16/32/44.1/48KHz

Audio Bit Rate 16~256kbps

Two-way Audio Support

Interface

Ethernet 1*RJ45 10M/100M Ethernet Port

Audio I/O 1/1

Alarm I/O 1/1

Mobile Communication Parameter

Wireless Communication Support 5G/4G/3G

Frequency Bands 5G NR: n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/n66 /n70/n71/n75/n76/n77/n78/n79

LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20 /B25/B26/B28/B29/B30/B32/B66/B71

LTE-TDD: B34/B38/B39/B40/B41/B42/B48

LAA: B46

WCDMA: B1/B2/B4/B5/B8/B19

Wireless Transmission Speed SA: DL 2.4Gbps; UL 900Mbps

NSA: DL 3.4Gbps; UL 550Mbps

LTE: DL 1.6Gbps; UL 200Mbps

SIM Card Nano SIM

Network

Network Storage NAS(Support NFS, SMB/CIFS

Network Protocols IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2

Intelligent Analytics

Video Analysis Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed

Face Detection Detect and capture faces, get real-time snapshots;

The attributes include Age, Gender, Glasses, Mask and Cap.

Support Faces Privacy Mode, the detected faces in the face detection area will be mosaic automatically.

Object Counting& Report Count the number of objects crossing the line, optionally human and vehicle,

Support regional people counting for up to 4 detection areas

System

Storage Support microSD/SDHC/SDXC Card Local Storage, up to 1TB

Advanced Function Heat Map, BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, EIS, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark

SIP/VoIP Support Yes, Voice & Video-over-IP

Event Trigger Motion Detection, Network Disconnection, External Input, Audio Alarm, etc.

Event Action FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc.

System Compatibility ONVIF Profile G & M & S & T, API

General

Working Temperature -40℃~60℃

Working Humidity 0~90%(Non-condensing)

Power Supply PoE (802.3at) / DC 12V±10%

Power Consumption 9W MAX

14W MAX (With IR on)

Weather Proof 4KV

Surge Protection Up to IP67-rated for Weather-resistant Performance (Only for camera body)

Dimensions 320mmX134mmX126mm

320mmX134mmX208mm (With Antennas)

Weight 1650g

Warranty 3/5 Years
